Fanuc M-2000iA/1700L
Fanuc M-2000iA/1700L
The M-2000 series of Fanuc designed with 6 axes with a handling capacity of up to 2.3 tons and a range of up to 4.7 meters. He specializes in a wide range of applications for handling and palletizing heavy workpieces. His excellent vertical elevation of 6.2 meters and horizontal reach facilitates the performance to manipulate larger workpieces. Mainly suitable for the automotive or metallurgical industry.
Main specifications
Maximum Load of Robot: 1700 kg
Number of axis: 6
Maximum horizontal reach: 4683 mm
Repeatability: ± 0.27 mm
Controller: R30iB
Motion range (°)
Axis J1: 330°
Axis J2: 160°
Axis J3: 165°
Axis J4: 720°
Axis J5: 240°
Axis J6: 720°
Maximum Load of Robot: 1700 kg
Number of axis: 6
Maximum horizontal reach: 4683 mm
Repeatability: ± 0.27 mm
Controller: R30iB
Motion range (°)
Axis J1: 330°
Axis J2: 160°
Axis J3: 165°
Axis J4: 720°
Axis J5: 240°
Axis J6: 720°
