Fanuc M-10iD/12

Fanuc M-10iD/12

The M-10iD / 12 industrial robot characterized by its large payload capacity and hollow wrist, offers short cycle times, wiring protection, easy maintenance, and low system costs providing greater productivity with advanced servo technology for higher performance of acceleration.

The Fanuc M-10 series, specialized in articulated robots for light load handling, has a thin, hollow wrist that offers greater work space, ease of integration into work cells, and internal wiring to avoid interference with other devices. Robot series provides improved cycle times, high performance and is ideal for applications of collection, pick and place and machine tending.

R-30iB Plus control system
Main specifications

Maximum Load of Robot: 12 kg
Number of axis: 6
Maximum horizontal reach: 1420 mm
Repeatability: ± 0.08 mm
Controller: 30iB

Motion range (°)

Axis J1: 340° (360)°
Axis J2: 250°
Axis J3: 447°
Axis J4: 380°
Axis J5: 380°
Axis J6: 720°
