ES165RD II handling robot Motoman
ES165RD II handling robot Motoman
ES165RD II compact and slim design that provides high performance in pressing and other heavy load applications. has 6 axes of high speed and acceleration that reduce cycle times and increases production. Performs tasks in a large workspace manipulating large and heavy parts saves 70% power consumption while in motion and 25% during periods of inertia. equipped with the DX200 controller.
DX200 Controller
Main specifications
VARIANTS: | ES165RD II | ES200RD II |
Maximum Load of Robot: | 165 kg | 200 kg |
Number of axis: | 6 | 6 |
Maximum horizontal reach: | 3,140 mm | 3,140 mm |
Maximum vertical reach: | 4,782 mm | 4,782 mm |
Repeatability: | ±0.2 mm | ±0.2 mm |
Controller: | DX200 | DX200 |
Motion range (°)
VARIANTS: | ES165RD II | ES200RD II |
Axis S: | ±180° | ±180° |
Axis L: | +80°/-130° | +80°/-130° |
Axis U: | +208°/-112° | +208°/-107° |
Axis R: | ±360° | ±360° |
Axis B: | ±130° | ±125° |
Axis T: | ±360° | ±360° |
Maximum speed (°/s)
VARIANTS: | ES165RD II | ES200RD II |
Axis S: | 105°/s | 90°/s |
Axis L: | 105°/s | 85°/s |
Axis U: | 105°/s | 85°/s |
Axis R: | 175°/s | 120°/s |
Axis B: | 150°/s | 120°/s |
Axis T: | 240°/s | 190°/s |
Robot applications
Material handling
Machine tending
Press tending
