ABB IRB 4400 M94A
ABB IRB 4400 M94A
Fast, compact and versatile industrial robot.
An extremely fast, compact robot for medium to heavy handling. Exceptional all-round capabilities make it suitable for a variety of manufacturing applications.
The load capacity up to 45 kg at very high speeds usually permits handling of two parts at a time. M94A version with the S4 controller enables the RAPID programming instructions making programming easier.
General technical specifications
Payload: 45 kg
Arm reach: 1,95 m
Mft. Year: 1995-1997
Robot Info:
- Maximum Load of Robot: 30/45 Kg.
- Maximum Reach: 1,95 mm.
- Repeatability: 0,1 mm.
- Controller: M94A-M96 S4.
Robot Motion Speed:
- Axis 1: 150º/seg
- Axis 2: 120º/seg
- Axis 3: 120º/seg
- Axis 4: 225º/seg
- Axis 5: 225º/seg
- Axis 6: 225º/seg
Robot Applications:
- Cutting and deburring
- Die spraying
- Glueing and sealing
- Grinding and polishing
- Machine tending
- Material handling
- Packing
- Palletizing
