ABB IRB 4400
ABB IRB 4400
An extremely fast, compact robot for medium to heavy handling. Exceptional all-round capabilities make it suitable for a variety of manufacturing applications.
The S4C controller enables RAPID instructions making programming easier.
The load capacity up to 60 kg at very high speeds usually permits handling of two parts at a time.
Rapid maneuverability makes the IRB 4400 perfectly matched for applications where speed and flexibility are important.
The robust, rigid construction means long intervals between routine maintenance. Well-balanced steel arms with double bearing joints, a torque-strut on axis 2 and use of maintenance-free gearboxes and cabling also contribute to the very high levels of
reliability.
The drive train is optimised to give high torque with the lowest power consumption for economic operation.
Robot Info:
- Maximum Load of Robot: 30/45/60Kg.
- Maximum Reach: 1960 mm.
- Repeatability: 0,1 mm.
- Controller: M97A-M98A-M99 S4C.
Robot Motion Speed:
- Axe 1: 150º/seg
- Axe 2: 120º/seg
- Axe 3: 120º/seg
- Axe 4: 225º/seg
- Axe 5: 250º/seg
- Axe 6: 330º/seg
Robot Applications:
- Cutting and deburring
- Die spraying
- Glueing and sealing
- Grinding and polishing
- Machine tending
- Material handling
- Packing
- Palletizing
